CB-10S/20S/30S/40S/50S

Technical characteristics:

◆ Single-phase, charging for lead-acid,battery with 12/24V, overload protection, intergrated ampere-meter.
◆ Portable, suit for various cars, vans and light trucks.
◆ With Complete accessories: Charging cable(1.5+1.5)m, two clamps, exchangeable fuse, color box.

Description:

ITEM UNIT CB-10S CB-20S CB-30S CB-40S CB-50S
Input Voltage (V) 1PH/220V±15% 1PH/220V±15% 1PH/220V±15% 1PH/220V±15% 1PH/220V±15%
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60
AC Power Input (W) 45W-(6V) 180W(12V) 300W-(12V) 450W-(12V) 600W-(12V)
90W-(12V) 240W(24V) 490W-(24V) 750W-(24V) 1000W-(24V)
Charging Voltage (V) 12/24 12/24 12/24 12/24 12/24
Max Charging Current (A) 10.0 20.0 30.0 40.0 50.0
Quick Charge Current (A) 8/5 18/12 30 45 60
Battery Capacities (Ah) 20-100 60-200 90-250 100-300 120-320
Insulation Class   H H H H H
Protection Degree (IP) IP21S IP21S IP21S IP21S IP21S
Packing Size (cm) 51x27x33.5 51x27x33.5 51x27x33.5 51x27x33.5 51x27x33.5
Weight (KG) 15.0 17.0 19.0 20.5 22.0
